Bucket cylinder – installation (2)
2.03.5 · TAIKON KT18 Pro (D722) · 4 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Arm (dipper stick)TK-51-0004 | 1 | |
| 2 | Bucket cylinderTK-32-0010 | 1 | |
| 3 | Pin 1TK-52-0014 | 1 | |
| 4 | Pin 1TK-52-0010 | 1 |
