Canopy
4.01 · TAIKON C12 · 7 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Canopy post, frontTK-62-0157 | 1 | |
| 2 | Canopy post, frontTK-62-0157 | 1 | |
| 3 | Canopy post, frontTK-62-0157 | 1 | |
| 4 | Canopy roofTK-62-0158 | 1 | |
| 5 | Hexagon flange bolt M8×20TK-81-0014 | 6 | |
| 6 | Hexagon flange bolt M10×30TK-81-0062 | 8 | |
| 7 | Nut M10TK-81-0063 | 8 |
