Boom
2.02 · TAIKON C12 · 5 items
Tap a number on the drawing to find the part in the list.
is shown on the drawing but the factory parts table does not list it. Send us a request and we will identify the part. Parts request →
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Boom (welded)TK-51-0008 | 1 | |
| 2 | Bent plateTK-62-0069 | 1 | |
| 3 | LED work light (9 LED)TK-71-0008 | 1 | |
| 4 | Protective sleeveTK-52-0031 | 4 | |
| 6 | Hexagon flange bolt M10×20TK-81-0039 | 2 |
