Covers
1.02 · TAIKON C12 · 17 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Side panel, left frontTK-62-0163 | 1 | |
| 2 | Side panel, left rearTK-62-0164 | 1 | |
| 3 | Side panel, right frontTK-62-0165 | 1 | |
| 4 | Side panel, right upperTK-62-0148 | 1 | |
| 5 | CounterweightTK-62-0166 | 1 | |
| 6 | Perforated panelTK-62-0149 | 2 | |
| 7 | Rear door panelTK-62-0151 | 1 | |
| 8 | Rear hood lockTK-62-0063 | 1 | |
| 9 | Latch striker (hasp)TK-62-0167 | 1 | |
| 10 | Upper coverTK-62-0168 | 1 | |
| 11 | Service panelTK-62-0169 | 1 | |
| 12 | Connecting plateTK-62-0153 | 2 | |
| 13 | Aluminium alloy hingeTK-81-0073 | 2 | |
| 14 | Nut M6TK-81-0031 | 12 | |
| 15 | Hexagon flange bolt M6×20TK-81-0026 | 4 | |
| 16 | Hexagon flange bolt M8×20TK-81-0014 | 6 | |
| 17 | Hexagon flange bolt M6×20TK-81-0026 | 12 |
