Seat base frame
1.04 · TAIKON C10 · 4 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Seat base frame (welded)TK-62-0066 | 1 | |
| 2 | Mounting part, rubber-tipped boltTK-81-0033 | 1 | |
| 3 | Connecting plateTK-62-0067 | 1 | |
| 4 | Hexagon flange bolt M8×20TK-81-0014 | 4 |
