Rear hood
1.03 · TAIKON C10 · 10 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Rear housingTK-62-0059 | 1 | |
| 2 | Mesh panel, rear housing, upperTK-62-0060 | 1 | |
| 3 | Mesh panel, rear housing, lowerTK-62-0061 | 1 | |
| 4 | Lock mounting assemblyTK-62-0062 | 1 | |
| 5 | Rear hood lockTK-62-0063 | 1 | |
| 6 | Hinge mounting partTK-81-0032 | 1 | |
| 7 | Fixed shaftTK-52-0018 | 1 | |
| 8 | Latch locating pieceTK-62-0064 | 1 | |
| 9 | Connecting pieceTK-62-0065 | 1 | |
| 10 | Nut M6TK-81-0031 | 12 |
