Coolant hoses (suction & return)
1.09.4 · TAIKON LT16 Pro · 6 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Diesel engine LL308TK-11-0011 | 1 | |
| 2 | Combination radiator (coolant / hydraulic oil)TK-12-0014 | 1 | |
| 3 | Coolant hose, return (upper)TK-12-0015 | 1 | |
| 4 | Coolant hose, suction (lower)TK-12-0016 | 1 | |
| 5 | Wire hose clamp 1TK-81-0066 | 2 | |
| 6 | Double-wire hose clamp 2TK-81-0067 | 2 |
