Upper structure – overview
1.00 · TAIKON LT16 Pro · 9 items
Tap a number on the drawing to find the part in the list.
is shown on the drawing but the factory parts table does not list it. Send us a request and we will identify the part. Parts request →
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Operator console – installation kitTK-90-0125 | 1 | |
| 2 | Covers – installation kitTK-90-0126 | 1 | |
| 3 | Engine – installation kitTK-90-0127 | 1 | |
| 4 | Cover frame – installation kitTK-90-0128 | 1 | |
| 5 | Hydraulic oil tank – installation kitTK-90-0129 | 1 | |
| 6 | Battery – installation kitTK-90-0130 | 1 | |
| 7 | Fuel tank – installation kitTK-90-0131 | 1 | |
| 8 | Radiator and air filter – installation kitTK-90-0132 | 1 | |
| 9 | Two-position six-way valve – installation kitTK-90-0133 | 1 |
