Bucket – installation
2.04.1 · TAIKON KT18 Pro (D722) · 5 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | BucketTK-53-0005 | 1 | |
| 2 | Bushing 1TK-52-0013 | 1 | |
| 3 | Arm (dipper stick)TK-51-0004 | 1 | |
| 4 | Pin 1TK-52-0014 | 2 | |
| 5 | BushingTK-52-0015 | 4 |
