Rear hood hinge
1.05.3 · TAIKON KT18 Pro (D722) · 5 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Cover frame ReferenceTK-62-0003 | 1 | |
| 2 | Rear hood hinge, main part (welded)TK-62-0028 | 1 | |
| 3 | Rear hood hinge, counterpart (welded)TK-62-0029 | 1 | |
| 4 | Stop plateTK-62-0030 | 1 | |
| 5 | Hood stay rodTK-62-0031 | 1 |
