Covers – overview
1.02.0 · TAIKON KT18 Pro (D722) · 8 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Side cover fittings, right – installation kitTK-90-0016 | 1 | |
| 2 | Middle cover panel fittings – installation kitTK-90-0017 | 1 | |
| 3 | Front cover – installation kitTK-90-0018 | 1 | |
| 4 | Side skirt, right – installation kitTK-90-0019 | 1 | |
| 5 | Side cover, right – installation kitTK-90-0020 | 1 | |
| 6 | Side skirt, left – installation kitTK-90-0021 | 1 | |
| 7 | Side cover, left – installation kitTK-90-0022 | 1 | |
| 8 | Rear hood – installation kitTK-90-0023 | 1 |
