Console mounting plate
1.01.4 · TAIKON KT18 Pro (D722) · 3 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Cover frame ReferenceTK-62-0003 | 1 | |
| 2 | Middle cover panelTK-62-0004 | 1 | |
| 3 | Access doorTK-62-0005 | 1 |
