Undercarriage – overview
3.00 · TAIKON KT18 Pro (D902) · 4 items
Tap a number on the drawing to find the part in the list.
is shown on the drawing but the factory parts table does not list it. Send us a request and we will identify the part. Parts request →
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Dozer blade – installation kitTK-90-0225 | 1 | |
| 2 | Tracks & rollers – installation kitTK-90-0226 | 1 | |
| 3 | Rotary joint (centre swivel) – installation kitTK-90-0227 | 1 | |
| 4 | Cover plate (hydraulic tank)TK-63-0020 | 1 |
