Travel control & pedals – installation
1.01.2 · TAIKON KT18 Pro (D902) · 12 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Ball joint, control linkage, rightTK-61-0004 | 1 | |
| 2 | Ball joint, control linkage, leftTK-61-0003 | 1 | |
| 3 | Ball joint, control linkage, centreTK-61-0005 | 1 | |
| 4 | Travel pedalTK-61-0006 | 3 | |
| 5 | Travel pedal bracket 2TK-61-0016 | 1 | |
| 6 | Control lever, rightTK-61-0010 | 1 | |
| 7 | Control lever, leftTK-61-0008 | 1 | |
| 8 | Control lever, centreTK-61-0009 | 1 | |
| 9 | Cast lever 3TK-61-0015 | 2 | |
| 10 | Cast lever 2TK-61-0013 | 1 | |
| 11 | PinTK-52-0001 | 1 | |
| 12 | Connecting rodTK-61-0014 | 1 |
