Upper structure – overview
1.00 · TAIKON KT18 Pro (D902) · 9 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Covers – installation kitTK-90-0199 | 1 | |
| 2 | Counterweight – installation kitTK-90-0200 | 1 | |
| 3 | Engine – installation kitTK-90-0201 | 1 | |
| 4 | Cover frame – installation kitTK-90-0202 | 1 | |
| 5 | Battery – installation kitTK-90-0203 | 1 | |
| 6 | Hydraulic oil tankTK-63-0014 | 1 | |
| 7 | Fuel tankTK-63-0015 | 1 | |
| 8 | Radiator and air filter – installation kitTK-90-0204 | 1 | |
| 9 | Upper structure frame ReferenceTK-62-0179 | 1 |
