Bucket link – installation
2.03.3 · TAIKON KT16 Pro · 3 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Arm (dipper stick)TK-51-0016 | 1 | |
| 2 | Bucket link (connecting rod)TK-51-0006 | 1 | |
| 3 | Pin 1TK-52-0035 | 2 |
