Arm & arm cylinder – installation
2.03.1 · TAIKON KT16 Pro · 5 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Arm (dipper stick)TK-51-0016 | 1 | |
| 2 | Arm cylinderTK-32-0019 | 1 | |
| 3 | Boom (welded)TK-51-0015 | 1 | |
| 4 | Pin 2TK-52-0032 | 1 | |
| 5 | Pin 2TK-52-0033 | 1 |
