Rear hood hinge
1.05.3 · TAIKON KT16 Pro · 4 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Upper structure cover frameTK-62-0089 | 1 | |
| 2 | Movable door panelTK-62-0101 | 1 | |
| 3 | PinTK-52-0001 | 1 | |
| 4 | Connecting rodTK-61-0014 | 1 |
