Upper structure – overview
1.00 · TAIKON KT16 Pro · 8 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Operator console – installation kitTK-90-0080 | 1 | |
| 2 | Covers – installation kitTK-90-0081 | 1 | |
| 3 | Engine – installation kitTK-90-0082 | 1 | |
| 4 | Cover frame – installation kitTK-90-0083 | 1 | |
| 5 | Hydraulic oil tank – installation kitTK-90-0084 | 1 | |
| 6 | Battery – installation kitTK-90-0085 | 1 | |
| 7 | Fuel tank – installation kitTK-90-0086 | 1 | |
| 8 | Radiator and air filter – installation kitTK-90-0087 | 1 |
